Allen-bradley 22B-d1P4N104 Powerflex 40 Adjustable Frequency Ac Drive
Allen-bradley
Series: A
Cat No: 22B-d1P4N104
Ip20/Ul Open-type With Top Cover Removed (Rated -10C To 50C Ambient).
Ip30/Nema 1/Ul Type 1 With Top Cover And Optional Conduit Box Kit
Motor Rating: 0.4Kw/0.5Hp
Input: 3 Phase, 380-480V, 48-63Hz
Ac Voltage Range: 352-528
Amps: 1.8
Output: 3 Phase, 0-400Hz
Ac Voltage Range: 0-460
Continuous Amps: 1.4
60 Sec Ovld Amps: 2.1
Short Circuit Current: 100Ka
Power Terminal Wire:
Use 75C Cu Wire
5.3 Mm2-1.3 Mm2 (10-16 Awg)
Torque 1.96 Nm (17.4 In-lbs)
Frn: 6.01
Made In China
Weight: 1.560 Kg
