Tungaloy 2QP-CCGW09T308 BXM20 CBN Turning Insert TiCN Finish, Neutral, 0.382″ Long, 3/8″ Inscribed Circle, 0.0313″ Corner Radius, 0.1563″ Thick, Diamond
Manufacturer Part #: 6805037
S/N: 12177234
UNSPSC: 23242105
(Minimum Order Quantity=1, Package Quantity=1)
Specifications:
| Relief Angle |
7 |
| Insert Style |
CCGW |
| Corner Radius (Inch) |
1/32 |
| Corner Radius (Decimal Inch) |
0.0315 |
| Included Angle |
80degree |
| Manufacturer Grade |
BXM20 |
| Coating/Finish |
TiCN |
| Wiper Edge |
No |
| Insert Hand |
Neutral |
| Insert Thickness |
3.97 |
| Insert Thickness (Inch) |
5/32 |
| Insert Thickness (Decimal Inch) |
0.1563 |
| Series |
2QP-CCM/GW |
| Inscribed Circle (Inch) |
3/8 |
| Inscribed Circle (Decimal Inch) |
0.3750 |
| Insert Material |
Polycrystalline Cubic Boron Nitride (PCBN) |
| Insert Shape |
Diamond 80 |
| Number Of Cutting Edges |
2 |
| Insert Shape Code |
C |
| Hole Diameter (Decimal Inch) |
0.1730 |
| Hole Diameter (Mm) ( – 0 Decimals) |
4.40 |
| Maximum Depth of Cut (mm) |
0.50 |
| Maximum Depth of Cut (Decimal Inch) |
0.0197 |
| Insert Holding Method |
Screw |
| Width (Inch) |
3/8in |
| Clearance Code |
C |
| Tolerance Code |
G |
| Coating Process |
PVD |
| Length Range (Decimal Inch) |
0.3000 – 0.4000 |
| Rake |
Positive |
| Insert Length (Decimal Inch) |
0.3820 |
| Primary Workpiece Material |
Hard Material |
| Primary Workpiece Material Code |
H |
| Iso Code |
CCGW09T308 |
| Standards |
ANSI, ISO |
| Manufacturers Catalog Number |
6805037 |
| Material Grade |
H10 |
| Single or Multi Tipped |
Multi Tipped |
| Proprietary Coating Designation |
TiCN |
| Coating Classification |
PVD |
| Chip Breaker |
Flat Top |
| Rake Angle |
0 |
| Cutting Edge Style |
Honed |
| Industry Standard Number |
2QP-CCGW 32.52 |
| Width (Decimal Inch – 4 Decimals) |
0.3750in |
| Multi-Use Tool |
Yes |
| Full Radius |
No |
| Multi-Use Application |
Turning, Facing, Boring |
| Tip Length (Decimal Inch) |
0.0870 |
| UNSPSC Code |
23242105 |
| Insert Size Code |
32.52 |
